Seguler 2003-2007 6.0L Ford Powerstroke Diesel EGR Cooler Delete Kit
by SEGULER

Seguler 2003-2007 6.0L Ford Powerstroke Diesel EGR Cooler Delete Kit

SKU SG-ER-0164
$56.14 - $56.14
$56.14
$56.14 - $56.14
$56.14
Availability:
in stock, ready to be shipped

Specifications-Expand to view details

-Fits:
Ford 6.0L diesel engines in the following vehicles:
2003-2007 F250 F350 F450 F550
2003-2007 Excursion
2005-2010 E-Series Vans
-Description:
100% Brand New, Never Been Used
Please check pictures for more details
High reliable
Professional installation is highly recommended
No instruction included
304 Stainless Steel and Billet Aluminum
Increase Performance by Getting More Fresh Air to Engine

Request a quote

FITMENT

  • 2003-2007 6.0L Ford F-250 Ford F-350 F-450 F-550 Super Duty.
  • 2003-2007 6.0L Ford Excursion SUV (Diesel Models Only).
  • 2005-2010 Ford E-Series Vans (E-250 E-350 E-450 Cargo/Passenger)
  • Will NOT fit 7.3L, 6.4L, or 6.7L engines.

DESCRIPTION

Product Overview

  • Anyone driving a 2003–2007 6.0L Ford Diesel understands that the stock EGR cooler is a critical ticking time bomb. Highly susceptible to severe soot buildup and fatigue cracking, a degraded OEM cooler dumps cooling fluid directly into the combustion chambers—triggering head gasket blowouts, hydro-lock, and total motor destruction.
  • Our Rugged EGR Delete Package replaces this failure-prone factory heat exchanger for good. By isolating the coolant circuit from the exhaust loop, it completely removes leakage risks while supplying unpolluted intake air, reducing running temperatures, and restoring lasting stamina to your Super Duty pickup.
Key Features
  • Premium billet aluminum and 304 stainless steel construction with precision CNC machining for maximum structural strength, corrosion resistance, and a lifetime leak-free seal
  • Blocks hot exhaust gas and permanently reroutes coolant away from the failure-prone factory EGR cooler assembly, eliminating the root cause of blown head gaskets
  • Halts the recirculation of sticky diesel ash and heavy soot through the intake manifold, keeping the engine fed with 100% fresh, clean intake air
  • Significantly drops both coolant temperature and engine oil temperature by removing the heat-soaking factory EGR cooler from the engine valley entirely

FAQ

Q: Will this fit my 7.3L or 6.4L Ford Powerstroke?

A: No, absolutely not. This kit is precision-engineered exclusively for the 2003–2007 Ford 6.0L V8 Powerstroke Diesel engine and 2005–2010 E-Series 6.0L vans. It will not work on any other displacement or model year.

Q: Where exactly on the engine does this kit install?

A: Underneath the intake manifold. The kit is designed to fully replace the factory EGR cooler, which resides deep in the engine valley of the 6.0L block, positioned directly beneath the intake manifold and adjacent to the oil cooler assembly.

Q: Where does the billet aluminum coolant reroute tube connect?

A: Between the oil cooler and the water pump. This precision J-tube attaches to the oil cooler cover port and redirects engine coolant directly back into the cooling circuit, completely bypassing the location where the old EGR cooler was previously mounted.

Q: Do I need to pull the intake manifold to complete this installation?

A: Yes, the intake manifold must be removed. Because the factory EGR cooler is buried deep in the engine valley, accessing it requires pulling the alternator, air intake system, turbocharger, and the intake manifold before the delete components can be installed.
