FITMENT
- 2011–2016 6.7L Ford F250 Super Duty V8 Diesel.
- 2011–2016 6.7L Ford F350 Super Duty V8 Diesel.
- 2011–2016 6.7L Ford F450 Super Duty V8 Diesel.
- 2011–2016 6.7L Ford F550 Super Duty V8 Diesel.
DESCRIPTION
Product Overview
-
Every 2011–2016 Ford 6.7L Powerstroke owner faces a common risk: factory Bosch CP4 high-pressure fuel pump failure. Because U.S. ultra-low sulfur diesel lacks sufficient lubricity, the CP4’s internal rollers can suddenly seize and metal-grind, sending aggressive metal shavings directly into your fuel system.
- Once contaminated, your high-pressure fuel rails, all 8 fuel injectors, lines, and gas tank are completely ruined—resulting in an unexpected $10,000+ repair bill. This Disaster Prevention Bypass Kit acts as a permanent firewall, blocking pump debris at the source and safeguarding your entire fuel injection system from total destruction.
Key Features
- Aircraft-Grade Billet Aluminum: Precision CNC-machined from anodized billet aluminum with high-pressure stainless steel hoses for maximum leak protection and corrosion resistance.
- Direct-Fit Engineering: Designed specifically for 2011–2016 Ford Super Duty trucks with exact OEM-style quick-connect fittings and pre-sized braided lines for a seamless install.
- Ultimate Fuel System Safeguard: Separates the CP4 internal lubrication return from the injector feed line, keeping metal shavings 100% isolated if the pump fails.
- Zero ECU Tuning Required: Maintains factory fuel pressure and flow parameter plug-and-play without triggering Check Engine Lights or modifying emission controls.
FAQ
Q: How does this CP4 Bypass Kit protect my engine's fuel system?
A: The kit separates the CP4 pump’s internal lubrication circuit from the fuel going to your injectors. If the pump fails, metal debris is trapped in a dedicated bypass line instead of destroying your high-pressure injectors, fuel rails, or fuel tank.
Q: What should I do if my CP4 pump actually fails after installing this kit?
A: If the CP4 pump fails, the kit contains the metal debris within the bypass circuit. You will only need to replace the failed CP4 pump itself and thoroughly flush the bypass block and lines, rather than replacing all 8 injectors, fuel rails, and the fuel tank.
Q: Will this bypass kit affect fuel pressure or engine performance?
A: No. The kit maintains factory fuel flow and pressure specifications to the high-pressure fuel rails. Your truck will retain of its original horsepower, torque, and fuel economy.
Q: How often should I inspect or clean the bypass components?
A: We recommend inspecting the bypass block and screen during every routine fuel filter change (typically every 15,000 to 22,500 miles). If you notice fine metallic shimmer or debris, it indicates early CP4 pump wear, allowing you to replace the pump before catastrophic failure occurs.
